SKU: KVASER 513-6 Categories: , Tag:


Designed for troubleshooting any CAN-based (controller area network) system, the Kvaser Memorator Light HS is an easy-to-use tool for logging serial data, with no preconfiguration or software setup required. With an autobaud function that determines CAN bus bit rate, the Kvaser Memorator Light can be attached to any high-speed CAN bus without configuration. All CAN bus traffic is logged in a circular buffer, overwriting the oldest data when the buffer becomes full. A separate circular buffer keeps track of error frame conditions and the message traffic that occurs near the conditions.

Additional information


# CAN Channels



10-1000 kbps

Mps Receive

20,000 mps

Msp Sending

Datalog to SD Card

Temperature Range

-40-85° C

IP 65 Rating

Galvanized Iso


CAN Bus Connection

D-SUB 9-pin





Weight 1 lbs

Data Sheet

Data Sheet

Single-Channel Kvaser Table

ThumbnailSKUName (click on link)WeightPrice# CAN ChannelsBitrateMps ReceiveMsp SendingCAN Bus ConnectionPC-ConnectionDatalog to SD CardTemperature RangeIP 65 RatingGalvanized Iso
KVASER U100KVASER CAN/CAN FD to USB1 lbs$459.00110-1000 kbps20,000 mps20,000 mpsD-SUB 9-pinUSB--40-85° CIP67Yes
KVASER 509-9KVASER LEAF PROFESSIONAL RUGGED HS1 lbs$946.00105-1000 kbps20,000 mps20,000 mpsD-SUB 9-pinUSB--40-85° CIP65Yes
KVASER 732-1KVASER LEAF LIGHT HS v2 OBDII1 lbs$315.00140-1000 kbps8,000 mps8,000 mpsJ1962USB--20-75° C-Yes
NE-USB-CAN-001SINGLE CHANNEL USB TO CAN INTERFACE1 lbs$315.00140-1000 kbps8,000 mps8,000 mpsD-SUB 9-pinUSB--20-75° C-Yes
KVASER 915-8KVASER LEAF LIGHT HS v2 J1939-13 TYPE II1 lbs$315.00140-1000 kbps8,000 mps8,000 mpsJ1939USB--20-70° C-Yes
KVASER 881-6KVASER LEAF LIGHT HS v2 M121 lbs$315.00140-1000 kbps8,000 mps8,000 mpsM12 5-pinUSB--20-70° C-Yes
KVASER 269-2KVASER LEAF PROFESSIONAL LIN1 lbs$415.00101-20 kbps--D-SUB 9-pinUSB--40-85° C-Yes
KVASER 513-6KVASER MEMORATOR LIGHT HS1 lbs$553.00110-1000 kbps20,000 mps-D-SUB 9-pinUSB--40-85° C--
KVASER 843-4KVASER LEAF PRO HS v21 lbs$742.00140-1000 kbps20,000 mps20,000 mpsD-SUB 9-pinUSB--40-85° C-Yes
KVASER 671-3KVASER BLACKBIRD V21 lbs$922.00140-1000 kbps15,000 mps15,000 mpsD-SUB 9-pinWIFI--40-70° C-Yes
KVASER OEM LEAFKVASER OEM LEAF SINGLE CHANNEL USB 1.0 CAN CABLE1 lbs$195.00140-1000 kbps8,000 mps8,000 mpsD-SUB 9-pinUSB 1.0--20-75° C--
KVASER 389-7KVASER LINX J15871 lbs$325.00101-20 kbps2,000 mps2,000 mpsJ1587USB--20-75° C--
