$2,105.00
Kvaser Memorator R SemiPro is a ruggedised, two channel CAN bus interface and standalone Datalogger. Standalone mode logs data to an expandable SD card slot; interface mode connects to the PC with USB2.0. The Memorator R SemiPro contains an advanced set of features: Message Filtering, Triggers, Error Detection Mode, Battery Backup, Integrated SD Card, Linx J1587 compatible, Galvanic Isolation and much more. Configurable using Kvaser’s included Memorator Tools software.
| # CAN Channels | 2 |
|---|---|
| Bitrate | 20-1000 kbps |
| Mps Receive | 20,000 mps |
| Msp Sending | 20,000 mps |
| Datalog to SD Card | Yes |
| Temperature Range | -40-85° C |
| IP 65 Rating | IP65 |
| Galvanized Iso | Yes |
| CAN Bus Connection | D-SUB 15-pin |
| PC-Connection | WIFI |
| BRAND | Kvaser |
|---|---|
| Wiki Link | https://wiki.neweagle.net/index.php?title=Kvaser#Memorator_R_SemiPro |
| ECCN # | EAR99 |
| Weight | 1 lbs |
| Thumbnail | SKU | Name (click on link) | Weight | Price | # CAN Channels | Bitrate | Mps Receive | Msp Sending | CAN Bus Connection | PC-Connection | Datalog to SD Card | Temperature Range | IP 65 Rating | Galvanized Iso |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | KVASER 821-2 | KVASER MEMORATOR 2xHS v2 | 1 lbs | $1,411.00 | 2 | 50-1000 kbps | 6,000 mps | 6,000 mps | D-SUB 9-pin | USB | Yes | -20-70° C | - | Yes |
 | KVASER 920-2 | KVASER USBcan R v2 | 1 lbs | $1,058.00 | 2 | 05-1000 kbps | 8,000 mps | 8,000 mps | D-SUB 9-pin | USB | - | -40-70° C | - | Yes |
 | KVASER 831-1 | KVASER USBCAN LIGHT 4xHS | 1 lbs | $791.00 | 4 | 50-1000 kbps | 8,000 mps | 8,000 mps | 26-pin HD D-SUB | USB | - | -19-75° C | - | Yes |
 | KVASER 417-7 | KVASER MEMORATOR PROFESSIONAL HS/LS | 1 lbs | $1,650.00 | 2 | 05-1000 kbps | 20,000 mps | 20,000 mps | D-SUB 9-pin | USB | - | -40-85° C | - | Yes |
 | KVASER 752-9 | KVASER USBcan PRO 2xHS v2 | 1 lbs | $1,087.00 | 2 | 50-1000 kbps | 20,000 mps | 20,000 mps | D-SUB 9-pin | USB | - | -40-85° C | - | Yes |
 | KVASER 819-9 | KVASER MEMORATOR PRO 2xHS v2 | 1 lbs | $1,519.00 | 2 | 50-1000 kbps | 20,000 mps | 20,000 mps | D-SUB 9-pin | USB | Yes | -40-85° C | - | Yes |
 | KVASER 714-7 | KVASER USBCAN LIGHT 2xHS | 1 lbs | $660.00 | 2 | 40-1000 kbps | 8,000 mps | 8,000 mps | D-SUB 9-pin | USB | - | -20-75° C | - | Yes |
  | KVASER 778-9 | KVASER MEMORATOR PROFESSIONAL 5xHS | 1 lbs | $3,280.00 | 5 | 40-1000 kbps | 20,000 mps | 20,000 mps | 26-pin HD D-SUB | USB | Yes | -40-85° C | - | Yes |
| KVASER 490-0 | KVASER MEMORATOR R SEMIPRO | 1 lbs | $2,105.00 | 2 | 20-1000 kbps | 20,000 mps | 20,000 mps | D-SUB 15-pin | WIFI | Yes | -40-85° C | IP65 | Yes |
